Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty

    Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers

    Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers
    • Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers
    • Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers
    • Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers
    • Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers
    • Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers
    • Buy cheap Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty from wholesalers

    Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty

    Ask Lasest Price
    Brand Name : COMI LIGHTING
    Model Number : B7TA-50W
    Certification : ETL, FCC,TUV, CE, ROHS,SAA,CB certificates.
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 100000pcs per month
    Delivery Time : 3-20days depends on order quantity
    • Product Details
    • Company Profile

    Anti UV PC Optics Lens Led Flood Lights 50W 7000LM High Lumen 5 Years Warranty

    COMI Lighting's B7TA-Series is a modular design LED tunnel light. B7TA operates from AC85-277V and offers models with different rated power ranging from 50W to 600W. It adopts high quality and high PF Mean Well or Sosen brand driver enables the lighting fixture with high efficiency up to 140lm/W. This lighting fixture is easy installed by angle adjustable bracket. The design of 6063 aluminium lamp housing and IP66 ingress protection level allows this series to fit outdoor applications and widely used for lighting for tunnel court, sports field, stadium, football field, golf course, tower crane, ports, square, building pillars, bridge, billboard, courtyard, road, outdoor, garbed trees and etc.


    Features and Benefits:
    ▪ Modular design for easy maintenance.
    ▪ Input Voltage AC85-277V,50/60Hz.
    ▪ Power Consumption:50W
    ▪ 84pcs Lumileds/Osram/Cree/Epistar 3030 chip as its light source.
    ▪ High light efficiency up to 140 lm/W.
    ▪ CRI: Ra>80.
    ▪ High quality Mean Well or Sosen brand LED Driver with high PF≥0.95.
    ▪ Anti-UV PC optics lens, transmittance rate> 94%.
    ▪ Beam angle options:10°/25°/45°/60°/90°/20*50°/30*70°/80*140°.
    ▪ Made of premium aluminium with good heat dissipation, compression and wear resistance.
    ▪ IP66 Waterproof rate for outdoor use.
    ▪ ETL, FCC,TUV, CE, ROHS,SAA,CB certificates.
    ▪ 5 Years warranty.


    certificates


    Material Specifications:

    Housing6063 Aluminium
    GasketDouble silicon-rubber rings
    LensPremium anti-UV PC optics lens ,transmittance> 94%,
    Beam angle options: 10°/25°/45°/60°/90°/20*50°/30*70°/80*140°.
    Cable GlandCopper and nickel coated
    LED, Lumileds, Osram, Cree, Epistar 3030 High Power LED, CRI80+
    PCBExcellent heat conductivity aluminium, coefficient of Heat Conductivity≥2.0w/mk
    LED DriverMean Well or Sosen Brand Constant Current LED Driver, PF≥0.95
    Power Cable0.5Meter 3-core : Brown(L), Yellow(G), Blue(N)
    Operating Temperature-20℃~+50℃
    InstallationAluminium Bracket (Angle Adjustable)

    Technical Specifications of 100W LED Tunnel Light / LED Flood Lighting:

    Item Number

    Power

    (W)
    Input
    Voltage
    (Vac)
    Light Source
    Beam Angle
    CCT(K)
    CRI
    (Ra)
    Luminous
    Flux (lm)±5%
    PF
    IP Rate
    B7TA-50W
    50W
    85-277Vac,
    50/60Hz
    84pcs
    3030 LED
    15°, 25°, 45°,
    60°, 90°, 20*50°,
    30*70°, 80*140°
    2700-6500K
    Ra≥80
    7000lm
    ≥0.95
    IP66

    Note: Specifications are subjected to change without notice.


    Dimension and Packaging Information for LED Tunnel Lights/ Flood Lights:

    Item Number
    Product Size
    Package Size
    N.W.
    G.W.
    Packaging
    B7TA-50W
    310*87*170mm
    344*190*135mm
    2.8KG
    3.2KG
    1piece/Carton
    B7TA-100W
    310*87*228mm
    344*258*135mm
    4.1KG
    4.5KG
    1piece/Carton
    B7TA-150W
    311*87*309mm
    344*334*135mm
    5.2KG
    5.8KG
    1piece/Carton
    B7TA-200W
    311*97*383mm
    420*350*135mm
    5.7KG
    7.4KG
    1piece/Carton
    B7TA-250W
    311*97*459mm
    495*350*135mm
    7.9KG
    8.5KG
    1piece/Carton
    B7TA-300W
    311*97*538mm
    590*350*135mm
    9.4KG
    10.1KG
    1piece/Carton
    B7TA-400W
    571*107*388mm
    614*435*135mm
    12.2KG
    13KG
    1piece/Carton
    B7TA-500W
    571*107*461mm
    614*520*135mm
    14.3KG
    15.2KG
    1piece/Carton
    B7TA-600W
    571*107*529mm
    614*614*135mm
    16.5KG
    17.5KG
    1piece/Carton

    Product family Series of B7TA LED Flood Lights/ LED Tunnel Lights:


    50-600W LED Tunnel light or floodlight_COMI LIGHTING_0


    Light Distribution Curve for Different Beam Angle of B7TA LED Floodlights/ LED Tunnel Lighting:


    Distribution curve for Different Beam Angle of LED Tunnel Light, Flood Lights_COMI LIGHTING LIMITED


    Exploded View of 50W/100W/ 250W/ 300W/ 400W/ 500W/ 600W LED Tunnel Lights/ LED Flood Lights:


    500W IP66 Outdoor CREE LUMILEDS OSRAM Led Tunnel Lighting with Mean Well Brand LED Driver 5 Years Warranty CE ROHS TUV FCC SAA Certficiates_1_0
