Circular LED Underground Lights 18W 27W 9x2W 3W Single / RGB / RGBW Color

Circular Underground Lights 18W 27W 9x2W or 3W in Single or RGB or RGBW Color Dimming DMX512 Controllable for outdoor Lighting surround round cylindrical pillar, or encircle tree or small flower nursery or parterre.

The COMI LANDSCAPE LIGHTING'S symetrical (B2FL) and asymmetrical (C2FL series) curved-type INGROUND LIGHTs are designed for inground integration and offers various design possibilities in architectural illumination, espcially for recessed mounting inground lights to surround round cylindrical pillar, or encircle tree or small flower nursery or parterre.

Features and benefits for IP67 Arc Recessed Underground Lights:
▪ Curved-shape or circular shaped designed for encircling lighting for tree or round pillar.
▪ Symmetrical light and asymmetrical light (35°|45°) for options.
▪ 6pcs or 9pcs 2W Osram LED/3W RGB LED.
▪ 24VDC, or 110-120Vac, or 220-240Vac 50/60Hz input.
▪ CRI(Ra)>80 (for 2200-6500K only).
▪ Color: 2200-6500K, Red,Green,Blue,Yellow and RGB.
▪ SUS316 stainless steel front cover and aluminum housing.
▪ Standard is non-dimmable by PWM, DALI, 0/1-10V.
Optional dimmable DALI, 0/1-10V support.
▪ Easy Vertical ground recessed install by mounting sleeve.
▪ Black back Plastic mounting sleeve included.
▪ IPclassification: IP67.
▪ 2 Years warranty.

Material Specifications for Recessed LED Underground Luminaire:

Housing	12# Die-casting grey powder coated aluminum. T=60-80μm Adhesion of ISO class 1/ASTM class 4B
Front Cover	SUS 316 Stainless steel
Light Window Glass	Step tempered glass.T=8mm
Cable Gland	IP-68 PG-9 PVC
Gasket	Tooling shaped seal
Driver	Constant current output
Operating Temperature	-20˚C~40˚C
Power Cable	▪ 1x cable 0.5meters H05RN-F 2X1.0mm² to open wires (Low voltage) ▪ 1x cable 0.5meters H05RN-F 3X0.75mm² to open wires(High voltage) ▪ 1x cable 0.5meters H05RN-F 4X0.75mm² to open wires(for RGB)
Mounting sleeve(Included)	PVC
Dimmable Support	TRIAC(High Voltage), Optional:DALI/ 0~10V/ PWM(Low voltage).

Technical Specifications for IP67 LED Underground Lamp:

Item Number	Length	Light Source	CRI	Lens Degree (Θ1/2)	Input voltage (V)	Typical Operating Current(mA)	Typical Power Consumption(w)	Typical Luminance (lm)	IK Rating
B2FR0657	373mm	6×2W Osram	Ra>80	30°	24VDC 120/240	24V=437 120V=107 240V=55	24V=10.5 120V=11.8 240V=12.1	Cool white=871 Warm white=566	09
B2FR0618	373mm	6×3W RGB 3in1 Full color	/	30°	24VDC	R=200 G=250 B=250	17	262	09
B2FR0957	428mm	9×2W Osram	Ra>80	30°	24VDC 120/240	24V=670 120V=164 240V=82	24V=16.2 120V=18 240V=18	Cool white=875 Warm white=570	09
B2FR0918	428mm	9×3W RGB 3in1 Full color	/	30°	24VDC	R=270 G=400 B=400	27	268	09

Notes:
1. Color: Mono (2000K,2400K,2700K, 3000K, 4000K, 6000K, Red,Green, Blue and etc.) , RGB.
2. The above items are with symmetrical light output, for asymmetrical light output types or frosted glass with soft light output type, please inquire separately.
3. Specifications are subjected to change without notice.

curved shape IP67 LED inground lights back view of curved shape IP67 LED inground lights curved shape IP67 LED underground lights
