CL-SR-2102HT 100-240VAC Input 3 channels both Master & Decoder Functions Switchable AC High Voltage DMX512 Controller with Output DC100-240V and up to 1 000W for RGB high voltage LED strip

The CL-SR-2102HT is a 3 channels AC high voltage both master&decoder functions switchable DMX512 controller designed for RGB high voltage LED strip. This AC high voltage DMX512 controller with 100-240VAC input and DC100-240V output, total output can be up to 1,000W , which can be perfect to control high voltage LED strip . This patented high volt control technology ensures smooth dimming and RGB color tone adjustment without any flickering. Both master mode and slave mode(also named as decoder mode) are available for this DMX512 controller and easy to switch between the two modes. While under slave mode, this controller works as a decoder which can be compatible with a variety of RGB DMX512 master controllers. While under master mode, the DMX512 controller works as a master controller that controls via the buttons and numeric digital display. Waterproof version(Model No.: CL-SR-2102HT(WP)) is available with IP67 rating which enables the high volt LED strip controller to be used in outdoor and damp environment.

Features and Benefits:

1. Leading Global High Voltage RGB DMX512 LED Controller.
2. Master Mode and Slave Mode(also named as decoder mode) Switchable.
3. 100-240VAC Wide Input and 100-240VDC Output.
4. 3 Channels, Total 5A Output.
5. Up to 1000W Output.
6. Patented High Voltage Control Technology, More Stable and Reliable Than Competitors’.
7. Perfect to Control High Voltage LED Strip.
8. Smooth and Accurate Brightness and RGB Color Tone Adjustment without Flickering.
9. Compatible with Varieties of RGB DMX512 Masters Under Slave mode(decoder mode).
10. Manual control via buttons and digital display under master mode.
11. Waterproof Version Available with IP67 Rating.

Specifications:

Dimension:

Typical Wiring Diagram:

For more information about this controller, please contact us separately.
