12V / 15V/ 24VDC 5633 - Series 1000mm IP65 Outdoor Linear LED Wall Washer with Round Symmetrical or Ellipse Asymmetrical Light Output

The compact yet powerful Armer™ Wall Washer Light 5633-Series LED Wall Washer features Compressed Mechanical seal and Nano Film Waterproof Breathable Plug to make the air pressure balance between the internal and external of lamp body and solve the mist and waterproof issue. The fixture uses high-intensity top grade high power LEDs, optical-grade PMMA lens and advanced heat dissipation mechanism anodized aluminum extrusion to provide exceptional photometric performance, energy efficiency and longevity. With a wide range of color consisting of warm white, natural white cool white and RGB to illuminate interior walls, exterior facades and unique architectural details with a rich, even wash or graze effect,and IP65 rated waterproof design, enables5633-Series Wall Washer is ideal linear lighting solution choice for most sophisticated, concentrated bright light output in both interior and exterior environments.

Features and Benefits:

● With Strong impact resistance 5mm thickness tempered glass cover;
● Utilizes Compressed Mechanical seal technology and Air pressure balance Nano Film Waterproof Breathable Plug to solve the waterproof/protection problem caused by thermal expansion and contraction.
Note:
Thermal expansion and contraction cause pressure difference btween internal and external of the lamp body,mist in interior lamp body and the waterproof problem and etc.Compressed Mechanical seal technology and Air pressure balance thread plug is to solve this basic problem of the outdoor wall washer.
● IP65 Rated design suitable for indoor and outdoor facade illumination and installation :
Designed to accommodate both interior and exterior environments where a rich, even wash is necessary.
● Advanced heat dissipation mechanism:
The internal heat management system for LED washer light enables the fixture with a higher stability and longer LED lifetime under -20℃~to 50℃ working temperature.
● Dimmable and worked with DMX:
(1) This mini wall washer can be dimmable with LED Dimming Controller(s) ;
(2) RGB version Work with DMX controller emits colorful lighting changing effect Over 16 million possible colors with red, green and blue LEDs;
● Cleverly adjustable brackets design:
its angle and side to side can be adjustable freely. The mounting holes on the brackets help to mount the fixture simply.
● Length,body color(Anodized Silver or black),led quantity,beam angle and etc can be customized made.

Material specifications:

General Information(For 1000mm Length only):

5. Lenth, LED quantity, working voltage, control way , Kelvin&Color and etc can be customize made.

Dimensional Drawing:
